BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 20 -
ESC –
Function:
Turn underline mode on/off
Code:
ASCII
ESC
-
n
Hex
1B
2D
n
Decimal
27
45
n
Range:
0 ≤ n ≤ 2, 48 ≤ n ≤ 50
Default:
n=0
Description:
■ This command enables the print data following it to be printer out underlined.
• The underline mode varied depending on the following values of n:
n
Function
0,48
Turns off underline mode
1,49
Turns on underline mode, set at 1-dot thick
2,50
Turns on underline mode, set at 2-dot thick
Remarks:
■ The spaces generated by horizontal tab are not underlined.
■ Using bit 7 of ESC !, the underline mode can be activated/deactivated as well.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
