SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 28 -
ESC J
Function:
Print and feed paper
Code:
ASCII
ESC
J
n
Hex
1B
4A
n
Decimal
27
74
n
Range:
0 ≤ n ≤ 255
Default:
None
Description:
This command prints the data in the print buffer and feeds the paper [n X vertical motion unit].
Remarks:
The maximum feed amount available varies depending on the printer model.
With standard mode selected, the vertical motion unit is used.
In page mode, the horizontal motion unit is applied when printing start poison is defined to the upper right or lower
right of print area using ESC T, otherwise, the vertical motion unit is used.
When used in page mode, this command moves only the print position, not executing actual printing.
Differences:
Vertical motion unit and maximum feed amount:
Model
Vertical unit
Max feed amount
SPP-R200II
0.125mm (1/203 inches)
31.875mm

Other manuals for BIXOLON SPP-R200II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BIXOLON SPP-R200II and is the answer not in the manual?

BIXOLON SPP-R200II Specifications

General IconGeneral
TypeMobile printer
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Compatible operating systemsWindows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory32 MB
Internal memory64 MB
Built-in barcodes1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width50 mm
USB portYes
Serial ports quantity1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technologyWired
Dimensions (WxDxH)79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)-30 - 70 °C
Operating temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)10 - 80 %
Ethernet LANNo
Battery voltage7.4 V
Power source typeBattery
Battery life (max)6.2 h
