BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 29 -
ESC L
Function:
Select page mode
Code:
ASCII
ESC
L
Hex
1B
4C
Decimal
27
76
Range:
None
Default:
None
Description:
This command switches from standard mode to page mode.
Remarks:
■ For printing in page mode, ESC T defines the print direction and starting position that is within the print area specified
by ESC W.
■ The conditions by the following commands are defined independently in standard mode and page mode.
• ESC SP, ESC 2, ESC 3, ESC U, and FS S
■ The following commands are not activated in page mode.
• ESC L, FS q, GS ( A, GS ( E, GS T
■ The following commands are not effective in page mode. The conditions set by these commands in page mode are
available when the printer returns to standard mode.
• ESC V, ESC a, ESC {, GS L, and GS W
■ The printer resumes standard mode by the use of ESC S, FF, and ESC@
■ In page mode, the command, FF, prompts printing the data in the printer buffer collectively. LF, CR, ESC J, and ESC
d just move the print position, not performing actual printing.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
