BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 30 -
ESC M
Function:
Select character font/ MSR card read
Code:
ASCII
ESC
M
n
Hex
1B
4D
n
Decimal
27
77
n
Range:
n = 0,1,2, 48, 49 ,50 ,67, 68, 69, 70, 71, 72, 73
Default:
n=0
Description:
▪ Selects only 1byte character fonts
▪ Selects Card reader mode
n
Function
0, 48
Character font A (12 × 24) selected
1, 49
Character font B (9 × 17) selected
2, 50
Character font C(9 x 24)selected
70
Set 1 track card reader mode
71
Set 2 track card reader mode
72
Set 1,2 track card reader mode
73
Transmits the MSR setting value(s)
67
Set 2 track card reader mode
68
Set 3 track card reader mode
69
Set 2,3 track card reader mode
66
Set 1,2,3 track card reader mode
99
Cancel MSR reader mode
■ Magnetic card reader is provided with track 1, 2, and 3.
■ Magnetic card read out put format
Refer to function 3 memory switch #7 (8 - 6 & 7 setting) of GS ( E command and function 1 of BS M S command.

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
