BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 33 -
1byte sentinel characters mode
02H
46H
31H
31H
1CH
1CH
(Header)
25H
(STX)
Max
DATA76
characters
(1Track
data)
3FH
(ETX)
1CH
(Separator)
3BH
(STX)
Max
DATA37
Characters
(2Track
data)
3FH
(ETX)
1CH
(Separator)
3BH
(STX)
Max
DATA104
Characters
(3Track
data)
3FH
(ETX)
03H
0DH
0AH
(End)
Multi byte sentinel character mode
START characters
(Max 10 byte)
Max DATA 76 characters
(1Track data)
END characters
(Max 10 byte)
0DH 0AH
START characters
(Max 10 byte)
Max DATA 37 characters
(2Track data)
END characters
(Max 10 byte)
0DH 0AH
START characters
(Max 10 byte)
Max DATA 104 characters
(3Track data)
END characters
(Max 10 byte)
0DH 0AH
■ The following shows the format of the MSR setting value transmitted from the printer.
Hexadecimal
Decimal
Amount of Data
Header
37H
55
1 byte
Flag
80H
128
1 byte
Data
41H ~ 48H
65 ~ 72
1 bytes
NUL
00H
0
1 byte
■ The following describes MSR read mode according to the MSR setting value.
MSR setting value(Hex)
MSR read mode
41
Track 1/2/3 read mode command (3 Track case)
42
Track 1 read mode AUTO trigger (3 Track case)
43
Track 2 read mode AUTO trigger (3 Track case)
44
Track 3 read mode AUTO trigger (3 Track case)
45
Track 1/2 read mode AUTO trigger (3 Track case)
46
Track 2/3 read mode AUTO trigger (3 Track case)
47
Track 1/2/3 read mode AUTO trigger (3 Track case)
48
MSR not used
