BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 37 -
ESC T
Function:
Select print direction in page mode
Code:
ASCII
ESC
T
n
Hex
1B
54
n
Decimal
27
84
n
Range:
0 ≤ n ≤ 3, 48 ≤ n ≤ 51
Default:
n = 0
Description:
This command selects the print direction and starting position in page mode.
n
Print Direction
Starting Position
0,48
Left right
Upper left
1,49
Bottom to top
Lower left
2,50
Right left
Lower right
3,51
Top bottom
Upper right
Remarks:
■ The print direction set by this command id not effective in standard mode.
■ If this command is processed in standard mode, the setting by this command is effective when the printer changes to
page mode.
■ Depending on the print starting position set by this command, the horizontal motion unit or vertical motion unit is used
for the following commands.
• When the starting position is the upper left or lower right of the print area; ESC SP, ESC $, ESC \ use the horizontal
motion unit and ESC 3, ESC J, GS $, GS \ the vertical motion unit.
• When the starting position is the upper right or lower left of the print area; ; ESC SP, ESC $, ESC \ use the vertical
motion unit and ESC 3, ESC J, GS $, GS \ the horizontal motion unit.
■ The setting of this command remains effective until ESC !, ESC @, printer reset or power cycling is executed.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
