BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 38 -
ESC W
Function:
Set print area in page mode
Code:
ASCII
ESC
W
xL
xH
yL
yH
dxL
dxH
dyL
dyH
Hex
1B
57
xL
xH
yL
yH
dxL
dxH
dyL
dyH
Decimal
27
87
xL
xH
yL
yH
dxL
dxH
dyL
dyH
Range:
0 ≤ (xL + xH x 256) ≤ 65535 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 255)
0 ≤ (yL + yH x 256) ≤ 65535 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 255)
1 ≤ (dxL + dxH x 256) ≤ 65535 (0 ≤ dxL ≤ 255, 0 ≤ dxH ≤ 255)
1 ≤ (dyL + dyH x 256) ≤ 65535 (0 ≤ dyL ≤ 255, 0 ≤ dyH ≤ 255)
Default:
When paper width of 48mm is selected:
(xL + xH x 256) = 0 (xL=0, xH=0)
(yL + yH x 256) = 0 (yL=0, yH=0)
(dxL + dxH x 256) = 384 (dxL=80, dxH=1)
(dyL + dyH x 256) = 2400 (dyL=60, dyH=9)
Description:
■ This command set the position and the size of the printing area in page mode as following.
• Horizontal starting position = [(xL + xH x 256) x (horizontal motion units)]
• Vertical starting position = [(yL + yH x 256) x (vertical motion units)]
• Horizontal printing area width = [(dxL + dxH x 256) x (horizontal motion units)]
• Vertical printing area width = [(dyL + dyH x 256) x (vertical motion units)]
Remarks:
■ The horizontal and vertical starting positions are out of the printable area, this command is canceled and the following
data is processed as normal data.
■ If (Horizontal starting position + Horizontal printing area width) is beyond the printable area, the Horizontal printing
area width is set to (Horizontal printing area - Horizontal starting position).
■ If (Vertical starting position + Vertical printing area width) is beyond the printable area, the Vertical printing area width
is set to (Vertical printing area - Vertical starting position).
■ This command is not effective in standard mode. If this command is processed in standard mode, the setting by this
command is effective when the printer returns to page mode.

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
