SRP-E300/302
Ver. 1.01 BIXOLON
- 15 -
DLE DC4
Function:
Generate pulse at real-time
Code:
ASCII
DLE
DC4
n
m
t
Hex
10
14
n
m
t
Decimal
16
20
n
m
t
Range:
n = 1, m=0,1, 1 ≤ t ≤ 8
Default:
None
Description:
■ Output the pulse specified by t to connector pin m as following:
m
Connector pin
0
Drawer kick-out connector pin 2
1
Drawer kick-out connector pin 5
■ This command generates the drive pulse to connector pin m with pulse width defined by t as following:
• Drawer kick-out connector pin 2 is selected with m=0 while pin 5 chosen for m=1.
• Pulse ON time is [t x100 ms] and OFF time [t x100 ms].
Remarks:
■ Upon receiving this command, the printer outputs the drive pulse to the specified connector pin.
■ The real time command is stored into the receive buffer and executed with higher priority than other commands.
Differences:
None
