BIXOLON SRP-E302 - Page 50

SRP-E300/302
Ver. 1.01 BIXOLON
- 50 -
ESC {
Function:
Turns upside-down printing mode on/off
Code:
ASCII
ESC
{
n
Hex
1B
7B
n
Decimal
27
123
n
Range:
0 ≤ n ≤ 255
Default:
n = 0
Description:
This command selects/deselects upside-down printing mode according to the least significant bit as follows.
LSB
Upside-down mode
0
Turned off
1
Turned on
Remarks:
■ This command is valid only when entered at the beginning of the line.
■ The upside-down print mode has no effect in page mode. If this command is processed in page mode, upside-down
printing mode is enabled when the printer returns to standard mode.
■ 180 rotated characters are printed from right to left in upside-down print mode.
■ The setting of this command remains effective until ESC !, ESC @, printer reset or power cycling is executed.
Example
Normal Upside- down Mode
Differences:
None
