SRP-E300/302
Ver. 1.01 BIXOLON
- 53 -
FS q
Function:
Define NV bit image
Code:
ASCII
FS
q
n
[xL xH yL d1...dk]1... [xL xH yL d1...dk]n
Hex
1C
71
n
[xL xH yL d1...dk]1... [xL xH yL d1...dk]n
Decimal
28
113
n
[xL xH yL d1...dk]1... [xL xH yL d1...dk]n
Range:
1 ≤ n ≤ 255
1 ≤ (xL + xH ×256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ (yL + yH ×256) ≤ 288 (0 ≤ yL ≤ 255, yH=0,1)
0 ≤ d ≤ 255
k = (xL + xH × 256) × (yL + yH × 256) × 8
Default:
None
Description:
■ This command defines the NV bit image in the NV memory.
• n denotes the number of the NV being defined.
• (xL, xH) and (yL, yH) set the number of dots in the horizontal and vertical directions to [(xL + xH × 256) x 8] and
[(yL + yH × 256) x 8] respectively for the NV bit image.
