BIXOLON SRP-E302 - Page 55

SRP-E300/302
Ver. 1.01 BIXOLON
- 55 -
GS !
Function:
Select character size
Code:
ASCII
GS
!
n
Hex
1D
21
n
Decimal
29
33
n
Range:
0 ≤ n ≤ 255
(1 ≤ Vertical enlargement ≤ 8, 1 ≤ Horizontal enlargement ≤ 8)
Default:
n = 0
Description:
■ This command selects the character height and width using bits 0 to 3, and bits 4 to 7 respectively as follows:
Bit
Function
Setting
0
Specifies the number of times normal font
size in the vertical direction
Refer to Table 2
[Enlarged in vertical direction]
1
2
3
4
Specifies the number of times normal font
size in the horizontal direction
Refer to Table 1
[Enlarged in horizontal direction]
5
6
7
• Table 1 [Enlarged in horizontal direction]
Hex
Decimal
Enlargement
00
0
1 time (standard)
10
16
2 times
20
32
3 times
30
48
4 times
40
64
5 times
50
80
6 times
60
96
7 times
70
112
8 times
