BIXOLON SRP-E302 Command Manual

SRP-E300/302
Ver. 1.01 BIXOLON
- 70 -
<Function 69> GS ( L pL pH m fn kc1 kc2 x y (fn=69)
Code:
ASCII
GS
(
L
pL
pH
m
fn
kc1
kc2
x
y
Hex
1D
28
4C
pL
pH
m
fn
kc1
kc2
x
y
Decimal
29
40
76
pL
pH
m
fn
kc1
kc2
x
y
Range:
(pL + pH x 256) = 6 (pL=6, pH=0)
m=48, fn=69
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
x=1, 2
y=1, 2
Default:
None
Description:
■ Prints the NV graphics data defined by the codes kc1 and kc2.
• The graphics data is enlarged by x and y in the horizontal and vertical directions.
Remarks:
■ This command prints the NV graphics data defined by Function 67.
■ In page mode, this command is not effective.
■ NV graphics data beyond the print area for one line is not printed.
Differences:
None
