Presettings
Operating instructions GLP
3 -- 89
6.562.98.5.01.18
Presets for prepackaging control
If fixed weight packages are to be checked for compliance with the preset weight
tolerances and a statistical evaluation created (see page 2 -- 28), the weight class
table can be configured appropriately! In the standard configuration with three
weight classes, the fixed weight labeling type is set in the middle weight class
column (see page 3 -- 91). The nominal weight Qn to be monitored is then
entered here (see page 3 -- 92), the statistics activated by activating the relevant
statistic type (see page 3 -- 93) and the type of statistic report preset (see page
3 -- 96). If zero is entered as the weight value then the weight saved under the
PLU data as the fixed weight is set as the nominal weight (see page 3 -- 92). The
various package weights can be monitored with a weight class table.
Depending on the type of statistics selected, with calculated or preset tolerance
limits, all packages are checked as a result. Packages outside the tolerance
range can be automatically ejected via appropriate presets. If all packages are
to be subjected to a statistical evaluation, the weight range of the middle weight
class column should be preset without limitation. Therefore, the following preset-
tings are advisable: Example:
1st weight class: up to 1 g, 2nd weight class: weighing range of scale, e. g. 6
kg, 3rd weight class: greater than 6 kg (see the following weight class table).
Weight class to Great.thanto0.001 kg 6.000 kg 6.000 kg
------
without
Fixed value
3
-----
------
------
------
------
3
0,200 kg
------
------
------
------
------
3
-----
------
------
------
------
------
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Labeling mode
Weight:
Package ejector
Statistics:
Factor To(1..30):
Statics display
Report for main statistic:
Min. level:
Max. level:
Report for marginal statistic:
Divider control
Divider 1
Divider 2
Divider 3
Divider 4
weighed
weighed
for USA
without
No. of packages for st. mean value
3
TOQn
0 kg 6 kg
TU2 TU1
Range stipulated
by the
Prepackaging
Regulations
(FPV)
TO range which can be
changed in steps via the
To factor (1...30)
TO
200 g
max. 479 g
182 g
(with a factor of To=3, TO = 236 g)
(with a factor of To=30, TO = 479 g)
236 g
All packages are accepted
A package too light and not accepted
is handled according to the presettings
of the neighboured left column.
A package too heavy and not accepted
is handled according to the presettings
of the neighboured right colum.
