Notes
Operating instructions GLP
6.562.98.5.01.18
4 -- 23
4.3.3 Dimensions of the operating terminal GT 240
286
80
203
4.3.4 Dimensions of the GT--CT
528
280
318
260
360
4.3.5 Power supply
230 V AC, 50 to 60 Hz, 0.65 A or
240 V AC, 50 Hz, 0.65 A or
110 V AC, 60 Hz, 1.2 A
Power cable: length approx. 2.5 m with European standard size plug
4.3.6 Protection type to DIN 40050
Labeler GLP 80/160 GT 240
Keyboard IP 54 IP 42
Display IP 54
Housing IP 21 IP 20
4.3
