5.5.5 Setting EPSON--LX 300 compatible printers
Character spacing 10 cpi
Shape of zero 0
Skip over--perfora-
tion
Off
Character table PC 437
Auto line feed Off
Page length 12 inches
Auto tear off Off
Tractor Single
Interface Auto selection (10 sec)
Bit rate 9600 bps
Parity None
Data length 8 bit
ETX / ACK Off
To allow the LX 300 printer to be switched to the compressed printing mode via
the interface, it must be manually set to the draft mode via its keyboard.
5.5.6 Pin assignment of RS232 cable for the EPSON--LX 300 printer
Since the LX 300 printer does not affect the RTS pin, the RS232 standard cable
cannot be used for the LX 300 printer. The DTRpin of the interface is used instead.
GX (9--pin D--Sub plug) Printer (25--pin D--Sub plug)
1 Protective ground not contacted 1 Protective ground
2 RxD 2 TxD
3 TxD 3 RxD
8 CTS 20 DTR
7 RTS 5 CTS
5 Signal ground 7 Signal ground
6 DSR
8 DCD
5
