Options
Operating instructions GLP
5 -- 11
6.562.98.5.01.18
Print suppress effective Yes
Auto LF No
Time out print Valid
Auto select No
Ribbon selection Black ribbon
Printhead gap adjust 0
Centering position DEFAULT
Parallel I/F I--Prime Buffer print
Pin 18 +5V
Auto feed XT Invalid
Serial I/F Parity None
Serial data 7/8 bits 8 Bits
Protocol Ready/busy
Diagnostic test No
Busy line RTS
Baud rate 9600 BPS
DSR signal Valid
DTR signal Ready on power UP
Busy time 1 sec
5.5.4 Pin assignment of RS232 cable for the EPSON--FX 80 printer
GX (9--pin D--Sub plug) Printer (25--pin D--Sub plug)
1 Protective ground, not contacted 1 Protective ground
2 RxD 2 TxD
3 TxD 3 RxD
8 CTS 4 RTS
7 RTS 5 CTS
5 Signal ground 7 Signal ground
6 DSR
8 DCD
20 DTR
5
