7
SPECIFICATIONS
NOTE: Specifications and information are subject to change without notice. Please visit www.bkprecision.com
for the most current product
information.
TTL OUTPUT
Level > 2.4V
Rise Time ≤20nS
Duty Cycle 50% typical
CMOS OUTPUT
Max Frequency 2MHz
Level 4V to 14V ±0.5V p-p,
Continuously variable
Rise Time ≤120nS
VCG (Voltage Controlled Generator) INPUT
Input Voltage
0 - 10V ±1V causes a 100:1 frequency change
Impedance
10 kΩ ±5%
FREQUENCY COUNTER
Accuracy
Time Base Accuracy ±1 count
Time Base Accuracy
±10 PPM (23 °C ±5 °C)
Display
4 digit LED
POWER SOURCE
120 / 230VAC ±10%, 50 / 60Hz, internal jumper
selectable
DIMENSIONS (H x W x D)
10-3/8" x 3-3/8" x 11-7/16" (26.4cm x 8.6cm x 29.1cm)
WEIGHT
4 lb. (1.8 kg.)
ACCESSORIES
Instruction Manual
Output Cable, BNC to Alligator Clips
