SPECIFICATIONS
FREQUENCY CHARACTERISTICS
Waveforms
Sine, Square, Triangle, ± Pulse, ± Ramp
Range
0.5Hz to 5MHz in 7 ranges
Resolution
4 digits
Tuning Range
Coarse: 10:1, Fine: ±5% of Coarse Setting
Variable Duty Cycle
15:85:15 Continuously Variable
Operating Modes
Normal, VCG (Voltage Controlled Generator)
Frequency Stability
Output frequency will not change more than 0.09% in 15
minutes after 1 hour warmup.
OUTPUT CHARACTERISTICS
Impedance
50 Ω ±10%
Level
20V p-p Open-circuit, 10V p-p into 50 Ω
Amplitude Control
Variable, 20dB range typical
Attenuation
-20 dB ±1 dB
DC Offset
Preset: ±0.1V typical
Variable: ±10V open-circuit, ±5V into 50 Ω
SINE WAVE
Distortion
3% typical at 1kHz
Flatness
±5% (.45 dB)
SQUARE WAVE
Symmetry
0.5Hz to 100kHz ≤2%
Rise Time
≤20nS
TRIANGLE WAVE
Linearity
≥98% to 100kHz
