Page #11 background imageLoading...
Page #11 background image
11
ENGLISH
(Original instructions)
u Work with the shoe pressed against the workpiece.
Hints for optimum use
u As some splintering along the line of cut on the top side of
the workpiece cannot be avoided, cut on the side where
splintering is acceptable.
u Where splintering is to be minimized, e.g. when cutting
laminates, clamp a piece of plywood onto the top of the
workpiece.
Pocket cutting (g. K)
Warning! Never tie the blade guard in a raised position. Never
move the saw backwards when pocket cutting. This may
cause the unit to raise up off the work surface which could
cause injury.
A pocket cut is one that is made when the edge of the material
does not push the lower guard open, but the bottom edge of
the rotating blade cuts into the middle of the material.
u Adjust the shoe (5) so the blade cuts at desired depth.
u Tilt the saw forward and rest front of the shoe on material
to be cut.
u Using the retracting lever, retract lower blade guard to
an upward position. Lower rear of shoe until blade teeth
almost touch cutting line.
u Release the blade guard (its contact with the work will
keep it in position to open freely as you start the cut).
u Remove hand from guard lever and rmly grip secondary
handle (7), as shown in gure N. Position your body and
arm to allow you to resist kickback if it occurs.
u Make sure blade is not in contact with cutting surface
before starting saw.
u Start the motor, allow saw to come to full speed, and then
gradually lower the saw until its shoe rests at on the
material to be cut. Advance saw along the cutting line until
cut is completed as shown in gure K.
u Release trigger and allow blade to stop completely before
withdrawing the blade from the material.
u When starting each new cut, repeat as above.
Troubleshooting
Problem Possible Cause Possible Solution
Unit will not
start.
Battery pack not
installed properly.
Check battery pack installation.
Battery pack not
charged.
Check battery pack charging
requirements.
Motor stops
while mowing.
Battery pack not
inserted into charger.
Insert battery pack into charger
until LED appears.
Charger not plugged in. Plug charger into a working out-
let. Refer to “Important Charging
Notes” for more details.
Surrounding air
temperature too hot or
too cold.
Move charger and battery to a
surrounding air teperature of
above 40 degrees F (4.5°C) or
below 105 degrees F (+40.5°C).
Problem Possible Cause Possible Solution
Unit shuts off
abruptly.
Battery pack has
reached its. maximum
thermal limit.
Allow battery pack to cool down.
Out of charge. (To
maximize the life of
the battery pack it is
designed to shutoff
abruptly when the
charge is depleted).
Place on charger and allow to
charge.
Accessories
The performance of your tool depends on the accessory used.
BLACK+DECKER accessories are engineered to high quality
standards and designed to enhance the performance of your
tool. By using these accessories you will get the very best
from your tool.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
u Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the new
plug.
u Connect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Follow the tting instructions supplied with good quality plugs.
Recommended fuse: 3 A.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries accord-
ing to local provisions. Further information is available at
www.2helpU.com

Other manuals for Black & Decker BDCCS18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Black & Decker BDCCS18 and is the answer not in the manual?

Black & Decker BDCCS18 Specifications

General IconGeneral
Blade bore1.2, 12.7 mm
Blade diameter140 mm
Idle speed (max)3700 RPM
Sound power level87 dB
Cutting depth (90º)43 mm
Sound pressure level76 dB
Diamond disc-
Vibration emission1.5 m/s²
Angle setting range0 - 45 °
Product colorBlack, Orange
Dust extraction portNo
Power sourceBattery
Battery voltage18 V
Battery capacity1.5 Ah
Saw blade includedYes
Number of batteries included1 pc(s)
