3
2.Removecoverandbatterycase.
3.InstallExteriorAssembly.
a.Removecoverfromassembly
byslidingcoverupandoff,see
gure.3
b.Removethebatterycasefrom
interiorassemblybyliftingthe
caseupandoutandsetaside,
seegure4.
Placetheexteriorassemblyushontodoor,
threadingthewireharnessunderthelatch.
Routetheconnectorofthewireharness
thoughtheslotattopofmountingplate.
Insertthelongscrewstoengageexterior
assembly.Tightenscrewstosecure-
makingsurethatboththeplateandthe
exteriorassemblyare
ushagainstthedoor
andverticallyaligned
withtheedgeofdoor.
4.InstallInteriorMountingplate.
Insertthehalfroundspindlethroughthelatch
fully-toengagewiththeexteriorassembly.
5.Installthehalfroundspindle.
Fig.4
Fig.3
Importantbeforeproceeding:
1.Verifythatposition#2ofthe“SettingsSwitch”isintheOFFposi-
tion.(Refertosection11.)
2. Workwiththedooropen(awayfromjamb)toavoidaccidental
lockout.
Wire
Harness
HalfRound
Spindle
Connector
LongScrews
MountingPlate
