Black & Decker SmartCode 40490-01 - Attach Connector to Interior Assembly; Install Interior Assembly

4
Important Note: To prevent damage, always handle the wire harness
at the connector (do not pull wires).
6.AttachtheConnectortotheInteriorAssembly.
ConnectorPort
Spindles
SmallScrews
SpindleOpenings
Interior
Assembly
Notch
Slot
a. Tuckinganyexcess
wirebackintoslotof
mountingplate,placethe
interiorassemblyondoor,
aligningthespindleswith
thespindleslotsofinterior
assembly.
7.InstallInteriorAssembly.
b.Onceushondoor,insertandtightensmall
screwstosecureassemblyontothemountingplate.
Note: To aid insertion of
screws, approach the screw
holes with the screw loaded
onto the screwdriver.
a.Aligntheconnectorwiththeconnectorportoftheinteriorassembly,
matchingnotchtoslot.
b.Oncealigned,pushtheconnectorinrmlytoconnect.
Connector
