the folded grey strip is against
the back of the cabinet overhang.
Tape the Mounting Template
securely in place. Check to be
sure the Mounting Template is
located where you plan to mount
the toaster.
NOTE: If the cabinet has an
overhang that extends more than
2 inches below the cabinet
bottom, a wooden shim (a piece
of wood that fits between the
Cabinet and the Bracket) will be
necessary. Cut a block of wood
that is: 16 1/4” x 5 1/2”. Make sure
the wood is at least as thick as
the amount of the overhang that
exceeds 2 inches. Locate and
drill holes on the shim for the
screws to pass through. (Longer
screws may be needed. See
Note after Step # 7.)
5. Mark the four drill holes
through the Template onto the
cabinet bottom with a pencil and
remove the Mounting Template.
(Figure J)
Cover the counter top to catch
drilled wood chips.
CAUTION: Suitable eye
protection is recommended to
prevent injury from shavings
while using a drill.
10
Figure J
