AC1037A | AC1037A-XMIT | AC1037A-REC
11
Switch Position EDID Information Source
Loop From loop-thru monitor
Internal Default Settings, Generated Internally
AC1037A-XMIT EDID SWITCH SETTINGS
The AC1037A units have a Bandwidth (BW) and Equalizer Setting Dip swicth located on
the front panel. The default factory settings is all switches in the off position. The default
equalizer (EQ) setting is for a short DVI cable, less than 10 feet. The default Bandwidth
(BW) setting is WIDE BW. This should work for most clean, “noise-free” DVI sources.
A narrow bandwidth setting should be used for dirty or noisy DVI sources.
Condition ( 1 ) ( 2 ) ( 3 ) ( 4 )
BW: Wide, EQ: Short Cable (<10 ft.) Off Off Off Off
BW: Medium, EQ: Short Cable(<10 ft.) On Off Off Off
BW: Narrow, EQ: Short Cable (<10 ft.) Off On Off Off
BW: Very Narrow, EQ: Short Cable (<10 ft.) On On Off Off
BW: Wide, EQ: Medium Cable (10-20 ft.) Off Off On Off
BW: Medium, EQ: Medium Cable (10-20 ft.) On Off On Off
BW: Narrow, EQ: Medium Cable (10-20 ft.) Off On On Off
BW: Very Narrow, EQ: Medium Cable (10-20 ft.) On On On Off
BW: Wide, EQ: Long Cable (20-30 ft.) Off Off Off On
BW: Medium, EQ: Long Cable (20-30 ft.) On Off Off On
BW: Narrow, EQ: Long Cable (20-30 ft.) Off On Off On
BW: Very Narrow, EQ: Long Cable (20-30 ft.) On On Off On
BW: Wide, EQ: Very Long Cable (30-45 ft.) Off Off On On
BW: Medium, EQ: Very Long Cable (30-45 ft.) On Off On On
BW: Narrow, EQ: Very Long Cable (30-45 ft.) Off On On On
BW: Very Narrow, EQ: Very Long Cable (30-45 ft.) On On On On
BANDWIDTH (BW) & EQUALIZER (EQ) SETTINGS
