The AC1037A-XMIT and AC1037A-REC units have three integral indicator LEDs that
are used to monitor the state of the units. The status of the LEDs are as follows:
TRANSMITTER and RECEIVER:
Power: ON (GREEN): Indicates that correct power has been
applied.
TRANSMITTER:
Video: OFF: Indicates no video detected on the input.
STEADY GREEN: Indicates DVI Video detected on the input.
Audio: OFF: Indicates no audio detected on the transmitter unit.
BLINKING GREEN: Audio detected on the transmitter unit.
RECEIVER:
Video: OFF: Indicates no video detected over the ber and, as a result,
no video present on the output.
STEADY GREEN: Indicates DVI Video detected over ber and, as a result,
video present on the output.
Audio: OFF: Indicates no audio detected over ber and, as a result,
no active audio detected by the receiver unit.
BLINKING GREEN: Audio detected over ber and, as a
result, active audio detected by the receiver unit.
