AC1037A | AC1037A-XMIT | AC1037A-REC
10
SYSTEM CONNECTIONS
The input and output connections for the AC1037A system is as follows:
Audio Connector (Transmitter & Receiver): 3.5mm stereo jack
Video Connector (Transmitter & Receiver): DVI-D connector
Video Pin Out: Transmitter Receiver
1 Red (-) Red (-)
2 Red (+) Red (+)
3 Red Shield Red Shield
4 N/C N/C
5 N/C N/C
6 DDC CLK DDC CLK
7 DDC Data DDC Data
8 N/C N/C
9 Green (-) Green(-)
10 Green (+) Greeen(+)
11 Green Shield Green Shield
12 N/C N/C
13 N/C N/C
14 +5V Power +5V Power
15 GND (for +5V) GND (for +5V)
16 Hot Plug Detect Hot Plug Detect
17 Blue (-) Blue (-)
18 Blue (+) Blue (+)
19 Blue Shield Blue Shield
20 N/C N/C
21 N/C N/C
22 Pixel Click Shield Pixel Click Shield
23 Pixel Click (+) Pixel Click (+)
24 Pixel Click (-) Pixel Click (-)
