Page 6
Chapter 1: Specifications
1. Specifications
Approvals UL
®
60950
Finish Black powder coat
Operating Environment Temperature: 32 to 104° F (0 to 40° C);
Humidity: 0 to 95%, noncondensing;
Elevation: 0 to 10,000 ft. (0 to 3048 m)
Connectors Power Input: C14 inlet w/Electromagnetic Interference (EMI) filter;
Power Output:
(2) 5-15R duplex receptacles (timed to alternate power between outputs every 15 minutes);
(1) non-timed receptacle
Power Input: 100–125 VAC, 60 Hz, 12 A max.;
Output: 12 A max. per outlet, 12 A max. per timer
NOTE: All outputs are protected by a single 15-A circuit breaker.
Dimensions 1.79"H (1U) x 6.13"W x 7"D (4.55 x 15.57 x 17.78 cm)
Weight 2.4 lb. (1.1 kg)
Warranty 3 years
The Black Box Double Diamond Warranty is our no-questions-asked warranty that protects your Black
Box timer from manufacturer defects, accidental damages, liquid spills, and power surges.
