Black Box ME475A - Page 6

2-W POINT-to-POINT APPLICATION
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
4 XMT+ XMT+ 4
5 XMT- XMT- 5
CONNECTION TO GROUND IS OPTIONAL
4-W POINT-to-POINT APPLICATION
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
3 RCV- XMT- 5
4 XMT+ RCV+ 6
5 XMT- RCV- 3
6 RCV+ XMT+ 4
CONNECTION TO GROUND IS OPTIONAL
4-W POINT-to-MULTIPOINT APPLICATION
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
3 RCV- XMT- 5
4 XMT+ RCV+ 6
5 XMT- RCV- 3
6 RCV+ XMT+ 4
1 2 3 4 5 6 7 8
XMT- 5
RCV+ 6
RCV- 3
XMT+ 4
2-W POINT-to-POINT APPLICATION
XMT+ XMT+
XMT- XMT-
CONNECTION TO GROUND IS OPTIONAL
4-W POINT-to-POINT APPLICATION
XMT+ RCV+
XMT- RCV-
RCV+ XMT+
RCV- XMT-
CONNECTION TO GROUND IS OPTIONAL
4-W POINT-to-MULTIPOINT APPLICATION
XMT+ RCV+
XMT- RCV-
RCV+ XMT+
RCV- XMT-
CONNECTION TO GROUND IS OPTIONAL
RCV+
RCV-
XMT+
XMT-
