STEP 03
With the help of another person, place the griddle body
upside down on a smooth, flat surface.
Loosen all eight (8) screws on the griddle body assembly
one (1) turn.
STEP 04
Slide the legs into the slots on the griddle body and use two
(2) M6x12 screws on each of the four corners to secure them to the
griddle body.
Tighten the eight (8) previously loosened screws on the griddle body.
STEP 05
Use four (4) M6 thumb screws to secure the legs to the
airfryer body.
STEP 06
With the help of another person, place the griddle unit on
its wheels.
Use eight (8) black countersunk M6x15 screws to attach the four (4)
side shelf brackets to the sides of the griddle body. (One side shelf
bracket (a) and side shelf bracket (b) on each side.)
a
a
b
