ASSEMBLY GUIDE

1 Body (1 piece) 2 Griddle top & Hood (1 piece) 3 Hood handle (1 piece)

4 Griddle handles (2 pieces) 5 Side burner

grate (1 piece)

6 Side burner

hard cover (1 piece)

7 Side burner

handle (1 piece)

8 Griddle feet

(4 pieces)

9 Regulator hose (1 piece) 10 Grease cup

(1 piece)

11 M6x12

screws (8 pieces)

12 M6 Flange

nuts (8 pieces)

13 M5 screw

(1 piece)

ILLUSTRATED PARTS LIST

TOOLS NEEDED: Phillips head screwdriver

& Adjustable wrench

NOT INCLUDED:

20 lb LP gas tank

Model 1860 | Owner’s Manual |

Assembly Guide
