Black Stone 1885 - ASSEMBLY GUIDE; Illustrated Parts List

ASSEMBLY GUIDE
ILLUSTRATED PARTS LIST
1 Body (1 piece) 2 Griddle Top (1 piece) 3 Bottom Shelf (1 piece)
4 Knobs (2 pieces) 5 Grease Cup (1 piece) 6 Side Shelf (1 piece)
7 Side Handle (1 piece) 8 Propane Tank Hanger (1 piece) 9 Propane Tank Support (1 piece)
10 Wheels (2 pieces) 11 M6x12
Screws (8 pieces)
12 M6 Nuts
(4 pieces)
13 Fixed Pins
(1 piece)
14 Cotter Pins
(1 piece)
15 M6x60 Thumb Screw (1 piece) 16 M6x40 Thumb Screw (1 piece) 17 M6x10 Thumb Screws (2 pieces)
EXPLODED VIEW
PARTS
QTY
1.1
Control Panel
1
1.2
Background Panel
1
1.3
Ignition Needles
2
1.4
Gas Rail
1
PARTS
QTY
1.5
H Burners
2
1.6
Regulator Hose
1
1.7
Le Leg Assembly
1
1.8a
Right Leg Assembly
1
PARTS
QTY
1.8b
Leg Caps
2
10.1
Wheel Frames
2
10.2
Wheels
2
3
5
2
1.5
1
6
4
8
10.1
10.2
1.1
1.2
1.3
1.4
1.6
7
1.8a
1.8b
9
1.7
Model 1885 | Owner’s Manual | | Owner’s Manual | Model 1885
06 07
Assembly Guide Assembly Guide
