| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
1
Griddle body (1 piece)
2
Griddle top (1 piece)
3
Bottom shelf (1 piece)
4
Hard cover (1 piece)
5
Hard cover handles (2 pieces)
6
Hard cover hooks (2 pieces)
7
Left side shelf (1 piece)
8
Right side shelf (1 piece)
9
Paper towel holder (1 piece)
10
Side handle (1 piece)
11
LPG hook (1 piece)
12
LPG support (1 piece)
13
Caster wheels
(2 pieces)
14
Fixed wheels
(2 pieces)
15
Grease cup
(1 piece)
16
Control knobs
(4 pieces)
17
Side shelf
bracket (L) (2 pieces)
18
Side shelf
bracket (R) (2 pieces)
19
Hardware pack (1 piece)
a. Shelf pegs (8 pieces)
b. M4x10 screws (4 pieces)
c. M6x12 screws (13 pieces)
d. M6 step bolts (8 pieces)
e. Small thumb screws (2 pieces)
f. Shelf peg washers (8 pieces)
g. Large thumb screw (1 piece)
h. Medium thumb screw (1 piece)
i. Shear pin (1 piece)
j. Cotter pin (1 piece)
k. Washers (2 pieces)
l. Acorn nuts (2 pieces)
m. Lock washers (2 pieces)
[a.]
[b.]
[c.]
[d.]
[l.]
[m.]
[e.]
[g.]
[h.]
[i.]
[k.]
[j.]
[f.]

