1
Body (1 piece)
2
Griddle top &
Hood (1 piece)
3
Left side shelf
(1 piece)
4
Right side shelf
(1 piece)
5
Stabilizing shelf
(1 piece)
6
Side handle
(1 piece)
7
Hood handle
(1 piece)
8
Grease cup
(1 piece)
9
Shelf basket
(1 piece)
10
LPG support
(1 piece)
11
LPG hook
(1 piece)
12
Paper towel
holder (1 piece)
13
Side shelf
bracket (L) (2 pieces)
14
Side shelf
bracket (R) (2 pieces)
15
Control knobs
(4 pieces)
16
Caster wheels
(4 pieces)
17
Logo panel
(1 piece)
18
Hardware pack (1 piece)
a. M6x12 bolts (18 pieces)
b. M6 step bolts (8 pieces)
c. Side shelf wing nuts (6 pieces)
d. Side shelf hooks (6 pieces)
e. Large thumbscrew (1 piece)
f. Medium thumbscrew (1 piece)
g. Slotted washers (6 pieces)
h. Shear pin (1 piece)
i. Cotter pin (1 piece)
j. Washers (6 pieces)
[a.]
[b.]
[e.]
[g.]
[j.]
[f.]
[d.]
[h.]
[i.]
[c.]

