Black Stone 2336 - Page 8

ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
STEP 10
Remove the lower two (2) step bolts from the right side shelf.
Hook the upper step bolts on the side shelf brackets. Use the two
previously removed step bolts to secure the side shelf to the side
shelf brackets.
Repeat with the left side shelf.
STEP 07
Loosen the lower bolts on either side of the griddle body.
Hook the front shelf keyholes onto these bolts and slide down
into place.
STEP 08
Remove the two (2) middle bolts from the right side of the
griddle body.
Use these bolts to attach one (1) side shelf bracket (L) and one (1)
side shelf bracket (R) to the right side of the griddle body.
Repeat with the left side of the griddle body.
STEP 09
Use three (3) wing nuts [n.], three (3) washers [m.], and
three (3) slotted washers [l.] to attach three (3) shelf hooks [k.] to
the left side shelf.
Repeat with the right side shelf.
L
L
R
R
[l.]
[m.]
L
L
R
R

