| OWNER’S MANUALASSEMBLY GUIDEMODEL:
IF YOU ARE USING AN LPG CYLINDER:
Insert the LPG cradle {20} into the cart base. Turn to secure.
STEP 05
Use twelve (12) large screws [e.] to attach three (3) slide
mounts {11} to the center cabinet panel.
Use twelve (12) large screws [e.] to attach three (3) slide mounts {11}
to the right cabinet panel.
IF YOU ARE NOT USING AN LPG CYLINDER:
Use four (4) large screws [e.] to attach the two (2) inner shelves {8}
to the cabinet.
STEP 04
Use three (3) large screws [e.] to attach the rear cabinet
panel {3} to the center cabinet panel.
Use four (4) large screws [e.] to attach the rear cabinet panel to the
cart base.
[e.] × 7
[e.] × 24
[e.] × 4
