| OWNER’S MANUALASSEMBLY GUIDEMODEL:
STEP 10
Use seven (7) large screws [e.] to attach one (1) countertop
slab {23} to one (1) countertop panel.
Repeat with the other countertop slab {23}.
STEP 11
Use four (4)
small screws [f.] to attach the two (2) door
hinges {13} to the left corner brackets.
STEP 12
Use six (6) large black screws [l.] to attach one (1) front
drawer panel {10} to one (1) drawer body {9}.
Repeat with the other two drawers.
STEP 13
Use two (2) small black screws [k.] and two (2) black
washers [j.] to attach one (1) drawer handle {12} to one (1)
drawer assembly.
Repeat with the other two drawers.
STEP 14
Pull out the two (2) drawer sliding tracks from the glide
housing. Insert the drawer slides into the cart tracks.
Repeat with the other two drawers.
(Note: to remove the drawer, depress the levers on the drawer rails.)
[e.] × 14
[k.] × 6
[j.] × 6
[l.] × 18
