Black Stone OMNIVORE 2322 User Manual

BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDEMODELS: 2322 • 2322CA
1
Body (1 piece)
2
Griddle top & Hood (1 piece)
3
Left side shelf (1 piece)
4
Right side shelf (1 piece)
5
Stabilizing shelf (1 piece)
6
Side handle (1 piece)
7
Hood handle and handle bezels (1 piece)
8
Grease cup
(1 piece)
9
Shelf basket
(1 piece)
10
LPG support
(1 piece)
11
LPG hook
(1 piece)
12
Paper towel
holder (1 piece)
13
Side shelf
bracket (L) (2 pieces)
14
Side shelf
bracket (R) (2 pieces)
15
Fixed wheels
(2 pieces)
16
Caster wheels
(2 pieces)
17
Control knobs
(4 pieces)
18
Hardware pack (1 piece)
a. M6x12 bolts (13 pieces)
b. M6 step bolts (8 pieces)
c. Shear pin (1 piece)
d. Cotter pin (1 piece)
e. Wing nuts (6 pieces)
f. Shelf hooks (6 pieces)
g. Slotted washers (6 pieces)
h. Steel washers (6 pieces)
i. Acorn nuts (2 pieces)
j. Lock washers (2 pieces)
k. Washers (2 pieces)
l. Small thumb screws (2 pieces)
m. Medium thumb screw (1 piece)
n. Large thumb screw (1 piece)
[a.] [b.] [c.]
[d.]
[e.]
[l.] [m.]
[n.]
[f.]
[g.]
[i.]
[k.]
[j.]
[h.]

