STEP 06
With two (2) M6X12 screws attach the paper towel holder onto the right side
shelf. Attach the right side shelf with four (4) M6X12 screws to the griddle
body. Place the garbage bag holder onto the griddle frame by aligning the rods
into the holes in the top of the right side panel as shown.
STEP 07
With four (4) M6X12 screws install the le side shelf onto the griddle body.
STEP 08
Using one (1) handle, a handle bezel, and two (2) M6X16 screws, attach the
handle to the griddle hood. Also, using two (2) M4 screws attach the cover
handle to the hard cover.
Rangetop Combo | Parts & Assembly
04
