Setup – Before Use (continued)
Installing the Handle
1. Insert the end of the Handle (34) into the handle
socket on the top of the Lifting Frame (36).
2. Secure the Handle in place with the Handle
Pin (29) and Cotter Pin (32). See Figure F.
Figure F
Handle Pin (29)
Lifting Frame (36)
Handle (34)
Cotter Pin (32)
