Mounting the Carrier to the Hitch Receiver
1. Slide the anti-tilt bracket (G) over the end of the hitch tube. The side with the three bolts should
face the vehicle hitch receiver.
2. With assistance, lift the empty carrier and slide the open end of the hitch tube into the hitch
receiver. Secure with the hitch pin and clip (K).
3. Slide the anti-tilt bracket up against the hitch receiver. Tighten the bolts against the underside of
the hitch receiver collar.
Operation
1. Remove the lock pin (N) to unlock the ramp (O).
2. Remove the ramp and place the end rung onto the
hook end of the platform (I), making sure the ramp is
securely in place. The bottom end of the ramp must
rest at on a solid, level surface when loading and un-
loading equipment.
3. Measure the motorcycle wheelbase to make sure the
wheel pins (M) are in the appropriate positions.
4. Shift the motorcycle into neutral and, with another per-
son’s assistance, push it up the ramp. Push the motor-
cycle completely onto the carrier platform until the front
wheel rests in place between the platform rungs. DO
NOT sit on the morotorcycle while loading or attempt to
drive it up the ramp.
5. Properly secure the motorcycle using tie down straps
(sold separately).
6. Return the ramp to the mounted position and secure
with the lock pin.
7. Attach any needed markers and/or lights to the carrier
and motorcycle as required by vehicle codes.
K
G
