Black+Decker BDINF20 - Safety Alert Symbols and Definitions; Safety Alert Symbols Explained; Inflator Component Identification

ENGLISH
1
English (original instructions)

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or propertydamage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety relatedmessage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
Fig. A
13
7
15
5
9
3
4
1
12
11
16
6
2
18
17
14
8
10
1
AC/DC power switch
2
Mode power switch
3
LCD
4
Pressure Setting button
5
Pressure Mode / Reset Button
6
Handle
7
High-volume hose
8
Tapered nozzle
9
Universal valve adapter
10
High-pressure hose
11
High-volume pump deflate connection
12
High volume pump inflator connection
13
120V AC cord
14
12V DC vehicle connector
15
20V MAX* battery slot
16
Inflator needle valve
17
Brass coupler adapter
18
Tapered nozzle
