7
ENGLISH
(Original instructions)
u Health hazards caused by breathing
dust developed when using your
tool (example:- working with wood,
especially oak, beech and MDF.)
Chargers
Your charger has been designed for a
specic voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate.
Warning! Never attempt to replace the
charger unit with a regular mains plug.
u Use your BLACK+DECKER charger
only to charge the battery in the
appliance with which it was supplied.
Other batteries could burst, causing
personal injury and damage.
u Never attempt to charge non-
rechargeable batteries.
u If the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
u Do not expose the charger to water.
u Do not open the charger.
u Do not probe the charger.
u The appliance/battery must be
placed in a well ventilated area when
charging.
Electrical safety
Symbols on the charger
+
Read all of this manual carefully before using the
appliance.
#
This tool is double insulated; therefore no earth wire
is required. Always check that the power supply
corresponds to the voltage on the rating plate.
$
The charging base is intended for indoor use only.
Labels on appliance
The following symbols appear on this appliance along with the
date code
+
Read all of this manual carefully before
using the appliance
BHFE520J use charger S010QU2300040
BHFE620J use charger S014CU2720050
Features
This tool includes some or all of the following features.
1. On/off power switch
2. Main handle
3. State of charge indicator
4. Charging port
5. Vacuum inlet
6. Extension tube
7. Accessory release latch
8. Dust canister
9. Floor head
10. 2 in 1 Accesssory tool
10a. Accesssory storage clip
11. Jack plug charger
12. LED worklight
Assembly (Fig. A, BF)
u Align the top of the extension tube (6) with the vacuum
inlet (5) as shown in Fig. A.
u Push the extension tube (6) onto the vacuum inlet (5) so
it locks into position.
u Align the bottom of the extension tube (6) with the oor
head (9) as shown in Fig. B.
u Push the bottom of the extension tube (6) onto the oor
head (9) so it locks into position.
u To remove an accessory, press the accessory release
latch (7) located on the vacuum or extension tube and
gently pull the connected accessory off.
Warning! When not in use position the unit with the rear of
the vacuum facing a wall so that any inadvertent fall of the unit
would contact a wall and not people or pets.
Charging the battery (Fig. C)
Warning! Use only with the supplied charger.
From new, the rechargeable cells of the product need a
minimum charge time of 5 hours to ensure full power.
Note: We recommend that you charge the unit in the storage
position as shown in figure T.
u The unit must be turned Off in order to charge.
u Fig. C - Plug the jack plug (13) of the jack plug
charger (11) into the charging port (4) of the vacuum.
u Plug the charger into a standard electrical outlet.
S010QU2300040
S014CU270050
