9
ENGLISH
(Original instructions)
u Once the lter housing is removed from the dust
canister, use your index nger and thumb to pinch the
lter tabs (17) and rotate the lter (22)
anti-clockwise and remove it as shown in gure L.
u Remove the foam lter (23) from the lter housing as
shown in gure M.
u Shake or lightly brush any loose dust off of the foam
lter (23) and lter (22).
u Rinse out the dust canister (8) with warm soapy water.
u Wash the lters with warm soapy water.
u Ensure the lters are completely dry before retting the
lters into the lter housing (18).
u Ret the clean and dry foam lter (23) into the lter
housing (18).
u Ret the clean and dry lter (23) into the lter (22) by
aligning the lter locks (24) , located on the sides
of the lter, with the lter housing slots (25) , located
on the sides of the lter housing, and turn the lter
clockwise until it locks rmly into position as shown in
gure N.
u Install the lter housing into the dust canister (8)
ensuring the dust canister slots align with the lter housing
tabs as shown in gure N1.
u Install the dust canister onto the vacuum, until it “clicks”
rmly into position.
Note: Ensure the dust port is placed towards the
main handle (2) of the vacuum and the dust canister
release button (15) is facing away from the vacuum (16).
Removing and cleaning the rotary brushes
(Fig. O, P, Q, R, S)
Warning! To reduce the risk of injury from moving parts,
disconnect the oor brush from the vacuum before cleaning
or servicing.
u To remove the rotary brush (26) from the oor head (9)
use a coin or straight screwdriver to rotate the lock (27) on
the lock plate (28) to the unlocked position (29) as shown
in gure O.
u Remove the lock plate (28).
u Ease the drive belt (9a) away from the rotary brush (26)
u The rotary brush (26) can now be removed.
Note: The bearings (33) are also removable from the end
pieces (32) allowing you to clear the brushes of any hair or
other debris that may have accumulated as shown in gure Q.
u Once the rotary brush has been cleaned, reinstall the
rotary brush into the oor head (9) as shown in gure R.
u Install the lock plate (28) onto the oor head (9) as shown
in gure S.
u Use a coin or straight screwdriver to rotate the lock (27)
on the lock plate (28) to the locked position (36) as
shown in gure S.
Safe storage (Fig. T)
The unit can be safely stored, when not in use, by placing the
catch on the motor unit (6b) onto the storage hook (6a) as
shown in gure T.
Maintenance
Your BLACK+DECKER cordless appliance has been designed
to operate over a long period of time with a minimum of main-
tenance. Continuous satisfactory operation depends upon
proper tool care and regular cleaning.
Warning! Before performing any maintenance on cordless
appliances:
u Run the battery down completely if it is integral and then
switch off.
u Unplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
u Regularly clean the ventilation slots in your appliance/
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Replacing the lters
The lters should be replaced every 6 to 9 months and when-
ever worn or damaged. Replacement lters are available from
your BLACK+DECKER dealer.
u Remove the old lters as described above.
u Fit the new lters as described above.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical Data
BHFE520J BHFE620J
Voltage 18V 21.6V
Watt Hours 36Wh 43.2Wh
Weight 2.02Kg 2.06Kg
