Black+Decker HSV320J32 - Functional Description; Assembly Instructions; Handle and Floor Head Installation; Hand Vac Installation and Removal

10
FUNCTIONAL DESCIPTION
1. On/off power switch
2. Handle
3. Rotary brush on/off button
4. Hand vac
5. Hand vac release button
6. Dust bowl
7. Floor head
8. Dust bowl release button
9. Charging indicator
10. Charger
11. Brush tool
(HSV420J42/ 520J01 only)
12. Crevice tool (HSV420J42/ 520J01 only)
13. Wall mount bracket (HSV520J01
only)
1
5
7
8
10
9
11
12
4
3
6
2
ASSEMBLY
INSTALLING /
REMOVING HAND V
AC
1
INSTALLING HANDLE /
FLOOR HEAD
1 3
2
13
