BlackSys CAMMSYS CH-100B - Left & Right

14
CAMMSYS BLACKBOX
Wi-Fi Port
Wi-Fi Connecting port
OBD Terminal
Check driving information
by using OBD cable
Rear Camera Connecting Port
Connecting HD rear camera
Power cable port
Cigar jack power cable port
GPS Port
Check location
and speed of vehicle
through BlackSys Viewer program
① GND
② AV OUT
③ GPS Data
④ Power
3-3 Left & Right
