USER MANUAL
- Hardware (H/W) Status LED
- Security Status LED
- Power ON/OFF
LED Red(REC) Green(Rear) Blue(GPS) Yellow(Wi-Fi)
Rear camera
Connect / Disconnect Connecting rear camera while operating / Rebooting when disconnecting
GPS
Connection success ON ON(2CH) ON -
Connection failed ON ON(2CH) OFF -
Wi-Fi
ON ON ON(2CH) - ON
OFF ON ON(2CH) - OFF
LED Red(REC) Green(Rear) Blue(GPS) Yellow(Wi-Fi) Security LED
Parking
Mode
Standby ON ON(2CH) ON(Connecting) ON(Connecting) Blink 3sec.
Motion Detection ON ON(2CH) ON(Connecting) ON(Connecting) Blink 1sec.
Parking Event ON ON(2CH) ON(Connecting) ON(Connecting) Blink 1sec.
Function Voice Guide Operating Status
Power ON
Starting the recording
Power OFF
Terminating the system
