Blagdon 4500 - Getting to Know Your Minipond Filter; Parts Description; How It Works; Technical Specification

GETTING TO KNOW YOUR MINIPOND FILTER GETTING TO KNOW YOUR MINIPOND FILTER
MINIPOND FILTER 4500 6000
Watts 5W 9W
Voltage 230V 230V
Hertz 50Hz 50Hz
Safety rating IP56 IP56
Cable 5 metres 5 metres
32
CC
_
CC
_
Part Description Spare Code
1 Filter body 1040570
2 Ceramic biomedia 1040587
3 Medium grade
foam pad
4 Fine grade foam pad 1040594
5 Coarse grade
foam pad
61
1
/2" outlet hose tail
7 Outlet O ring gasket 1040600
8 Outlet nut
9 Filter partition divider N/A
10 Polymer wool pad
11 Carbon foam pad
(2 wool & 2 carbon) 1010887
(6 wool & 6 carbon) 1010894
28
27
26
25
24
23
22
21
20
19
17
18
16
15
14
13
12
11
10
2
4
6
5
7
9
8
3
1
29
1
3
4
10,000 10,000ltr/2,200gal 7,500ltr/1,650gal 7,500ltr/1,650gal 5,625ltr/1,237gal 2,812ltr/618gal
14,000 14,000ltr/3,080gal 10,500ltr/2,310gal 10,500ltr/2,310gal 7,875ltr/1,732gal 3,937ltr/866gal
10,000 18W 5,000ltr/1,100gal 32mm/1
1
/
4
" 3x 40mm/1
1
/
2
"
14,000 24W 7,000ltr/1,540gal 40mm/1
1
/
2
" 4x 40mm/1
1
/
2
"
Part Description Spare Code
12 Cartridge clip
13 Filter pad cartridge
1040617
14 Spray bar cap
15 Spray bar
16 spray bar nut
1040624
17 Spray bar O ring gasket
18 UVC feet/hinge
locating screws 1040679
19 Filter lid 1040648
20 UVC electronics & cap
21 9w & 5w bulb
(9W) 1040655
(5W) 1041041
22 UVC O ring gasket 1041065
Part Description Spare Code
23 Quartz sleeve 9w/5w 1041058
24 UVC contact chamber 1040662
25 UVC feet/hinge 1040679
26 Inlet hose tail O ring
gasket 1040686
27 Inlet 1"
3
/4"
1
/2" hosetial 1040693
28 Inlet cap
29 Optional 1" 25mm
flow control valve 1040563
(not included)
TECHNICAL SPECIFICATION CHART
HOW IT WORKS
Minipond filters create a clean, clear and healthy pond
environment for your fish. A minimum of maintenance
is needed due to the unique five stage filter design.
1. High performance UVC clears green water algae.
2. Graded foam filter pads remove dirt and waste.
3. Ceramic biological filter media prevent the build
up of harmful toxins in the pond.
4. Replaceable polymer wool pad removes
fine waste particles and polishes the water.
5. Carbon impregnated pad removes chemical pollutants.
