Blanco A-STYLE 400-U User Manual

+2mm / -1mm
A B C R
BLANCO A-STYLE 400-U 400 mm 400 mm 27 mm 22 mm I
BLANCO A-STYLE 500-U 500 mm 400 mm 27 mm 22 mm I
BLANCO A-STYLE 340 / 180-U 545 mm 400 mm 27 mm 22 mm III
BLANCO C-STYLE 400-U 400 mm 400 mm 27 mm 10 mm I
BLANCO C-STYLE 500-U 500 mm 400 mm 27 mm 10 mm II
BLANCO C-STYLE 340 / 180-U 545 mm 400 mm 27 mm 10 mm III
BLANCO S-STYLE 400-U 400 mm 400 mm 22 mm 60 mm I
BLANCO S-STYLE 500-U 500 mm 400 mm 22 mm 60 mm I
BLANCO Z-STYLE 400-U 400 mm 400 mm 27 mm 1 mm I
BLANCO Z-STYLE 500-U 500 mm 400 mm 27 mm 1 mm II
BLANCO Z-STYLE 340 / 180-U 545 mm 400 mm 27 mm 1 mm III
BLANCO Z-STYLE 700-U 700 mm 400 mm 27 mm 1 mm II
BLANCO Z-STYLE 400/400-U 825 mm 400 mm 27 mm 1 mm IV
BLANCO ANDANO 180-U 180 mm 400 mm 27 mm 22 mm I
BLANCO ANDANO 340-U 340 mm 400 mm 27 mm 22 mm I
BLANCO ANDANO 340 / 340-U 705 mm 400 mm 27 mm 22 mm IV
BLANCO ANDANO 400-U 400 mm 400 mm 27 mm 22 mm I
BLANCO ANDANO 450-U 450 mm 400 mm 27 mm 22 mm I
BLANCO ANDANO 500-U 500 mm 400 mm 27 mm 22 mm I
BLANCO ANDANO 500 / 180-U 705 mm 400 mm 27 mm 22 mm III
BLANCO ANDANO 700-U 700 mm 400 mm 27 mm 22 mm II
BLANCO ANDANO 340 / 180-U 545 mm 400 mm 27 mm 22 mm III
BLANCO ANDANO 400 / 400-U 825 mm 400 mm 27 mm 22 mm IV
BLANCO ETAGON 500-U 500 mm 400 mm 27 mm 35 mm I
BLANCO ETAGON 700-U 700 mm 400 mm 27 mm 35 mm II
BLANCO SUPRA 340-U 340 mm 400 mm 22 mm 60 mm I
BLANCO SUPRA 340/340-U 715 mm 400 mm 27 mm 60 mm V
BLANCO SUPRA 400-U 400 mm 400 mm 22 mm 60 mm I
BLANCO SUPRA 450-U 450 mm 400 mm 22 mm 60 mm I
BLANCO SUPRA 500-U 500 mm 400 mm 22 mm 60 mm I
BLANCO YPSILON 340-U 340 mm 420 mm 22 mm 60 mm I
3
I
III
V
II
IV
x
x
x
x
x
x
C
Ø 5 mm
15 mm
l, ll, lll, lV, V
2
6
8
1
A: +2 mm / -1 mm = OK
B: +2 mm / -1 mm = OK
www.blanco-germany.com
DXF
PDF
4
60 mm
Ø 14 mm
Ø 35 mm
150 mm
9
12
42 mm
57 mm
1110
PZ2
PZ 2
13
5
OK
not OK
Sili
cone
PZ 2
PH 2
7

Blanco A-STYLE 400-U Specifications

General

Brand	Blanco
Model	A-STYLE 400-U
Category	Plumbing Product
Language	English
