Ventilation Requirement
All induction cooktops are fitted with cooling fans that draw fresh air in from the rear of
the unit and expel the warm air through vents at the front.
When installing your cooktop the following ventilation requirements are as follows:
5 mm ventilation cut out below the bench top the width of the cooktop.
10 mm ventilation cut out in the base of the kick plate.
50 mm gap behind the oven or draws.
A minimum gap of 30 mm between the oven and base of the cooktop.
Ventilation gaps should not be obstructed by any drawers, cupboards, etc.
This diagram is a typical example when fitted above an oven or drawers.
