1414
The following things should be checked before starting the dishwasher.
Start of Dishwasher Start of Dishwasher
The content of this manual is very helpful to the users.
After installation, please make sure to keep this manual.
Attention:Attention:
1 The dishwasher is level and fixed properly.
2 The inlet valve is open.
3 There is a leakage at the connections of the conducts.
4 The wires are tightly connected.
5 The power is switched on.
6 The inlet and drain hoses are knotted.
7 All packing and print materials should be taken out of the dishwasher.
Drain hose Connection
Insert the drain hose into a drain pipe with a minimum diameter of 40mm, or let it run into the sink, making sure to
avoid bending or crimping it. The top of the hose must be less than 1000mm.
MAX 1000mm
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
1000mm.
40mm
B
PLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, BPLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, B
