INSTRUCTIONS FOR THE INSTALLER
17
18
GAS CONNECTION
This appliance shall be installed only by
authorised personnel and in accordance with the
manufacturer’s installation instructions, local gas
tting regulations, municipal building codes, water
supply regulations, electrical wiring regulations,
AS 5601 - Gas Installations and any other
statutory regulations.
The appliance is adjusted to work with the gas
indicated on the label which is applied on the
glass-window of the oven door and on the cooker
packing.
Installation for Natural gas
Connect regulator (B) to tting (A) which is then
tted to elbow (F). Ensure arrow on regulator point
in the direction shown. Fitting (D) to be supplied by
installer (g. 18). Adjust regulator to give test-point
pressure given on data label on <TECHNICAL
FEATURES> paragraph, with one large or one
medium burner alight at maximum.
Position of Regulator (g. 17)
The stove must be installed on legs which come
with the product, a gas pipe between tting
(A) and (B) will allow location of the regulator
(B) underneath the stove for adjustment and
maintenance.
Installation for Propane Gas (g. 17A)
Connect by using a copper pipe starting, from the
threaded tting of elbow (F) .
Installation using exible connection
As an option, the cooker may be installed with a
exible connection hose, which complies with AS/
NZS 1869 (AGA Approved), 10 mm ID, class B or
D, Minimum 1000 mm - Maximum 1200 mm, as an
alternative connection.
• All cookers offer left or right hand connection.
The manifold has a at air over which is
inserted a screw nut male ½” gas (g. 18).
• An isolating tap and pressure regulator must
be xed to the rear wall and the exible pipe
attached by means of a union connector.
• The gas connection and isolating tap must be
accessible to a service person or inspector.
• The hose assembly must be installed in
accordance with AS5601 for a high level
connection. The hose should not be subjected
Note: When the regulator is tted at the rear of
the cooker at least 60 mm clearance is required.
to abrasion, kinking or permanent deformation
and should be able to be inspected along its
entire length. Unions compatible with the hose
ttings must be used and connections tested
for gas leaks. The xed consumer piping
outlet should be at approximately the same
height as the cooker connection point, pointing
downwards.
• The hose be clear of the oor when the cooker
is in the installed position. The hose chain which
is to be supplied by the installer
supplied should be anchored to the lower hook
xed to the wall so that the chain prevents
strain on the hose connections when the
cooker is pulled forward.
